Feeding The Material
Cutting depth
To avoid overheating or snapping the cutter, it is important not to overload it by cutting too deep in a single pass. Determining the optimum depth is largely a matter of experience and depends on several factors such as cutter shank size, power of the router, hardness of the material being cut, and the router feed speed.
As a rough guide the depth of cut should not exceed the diameter of the cutter when you are using cutters up to 1/2” diameter, or the diameter of the cutter shank, whichever is smaller.
Pyramid chart to assess cutting depths
If any of the criteria cannot be met, take several shallower passes until the full depth of cut is reached. You will soon develop a feel for when the correct cutting depth is being used as factors such as noise, feed resistance and drop in router speed will indicate when a deep cut is attempted.
Never force a cutter to rout too deep a cut in one pass, instead stop routing, re-adjust the cutting depth and try again.
Check you have reached the required depth by making a trial cut in a piece of scrap material. It is more reliable than trying to measure the cutter projection from the base of the router.
Guide to the chart
- The cutter has a standard shank length.
- The cutting length of the cutter is not excessive relative to the depth of cut.
- The workpiece is of medium density timber.
- A feed speed of 2-3 metres/minute is maintained.
- The cutting edges are clean and sharp.
- At least three quarters of the cutter shank is gripped in the collet.
Router speed
With the advent of electronic speed control the question of choosing the correct router speed arises. Recommended router speeds can vary depending on the power of the router, the type of material being cut and the feed speed. An important point to remember is that if the router is underpowered the cutting speed under load will be drastically reduced and a poor performance will result on all but the smallest size cutters. So several passes with the router should be made if a single deep pass causes the motor revolution count to drop below 70% of the no-load running speed. Using a sharp cutter at the correct peripheral speed will ensure a good finish.
If restricted to a single-speed router, you will not be able to run large diameter cutters at their optimum lower cutting speeds. One advantage of the variable speed feature is their 'soft start' when the motor slowly builds up speed and avoids the 'jerk' which can be disconcerting for some router users. For ascertaining the correct cutter speed relative to the diameter of the cutter, the peripheral speed can be calculated as follows:
Separate variable speed controllers are available for connecting the router and the power source. However, these are unlikely to offer full-wave rectification or speed compensation and do not maintain the available power evenly throughout the speed range. Inferior types of speed controllers can also affect the smooth running of a router, particularly at lower speeds.
Feed speed
To minimise wear on the router motor bearings, prevent cutter damage and improve the finish left on the cut face, it is important to maintain a constant and optimum feed speed.
Although an optimum feed speed or rate can be given, variations in the type of material, type and condition of the cutter and the available router power will have an effect on this. It is therefore down to the operator to judge by the sound of the router's motor whether the motor is laboured. In time, the operator will acquire a feel for the router, and a feed speed relative to the work in hand, will come naturally. It will be found that a narrow cutter can be used at a higher speed than a wider one, although very narrow cutters will need a slower feed speed and smaller depth of cut to prevent cutter breakage.
This is largely dependent on experience and a keen ear for what is happening to the noise from the motor. Feed rate varies with the composition of the material being cut, its hardness and the type of cutter being used.
For instance, a single flute cutter will clear faster than a two-flute one so you can feed it more quickly, although the resulting finish may not be as good.
If you feed too tentatively, heat is generated in the cutter and the friction causes the timber to burn and the cutter edges will overheat and suffer damage.
On the other hand, if you try and go too quickly the waste material will not clear fast enough, the router will slow down and again the finish will be poor.
It is only with practice that you will get a feel for the proper feed rate. Close observation of both the type of waste you are producing and the resultant surface finish is a good guide as to whether you are feeding properly.
If the bit is sharp you should be producing fine wispy shavings and leaving a clean, neatly severed finish on the work, particularly with natural timbers.
If you feed too slowly, the waste changes to powdery dust and there is some scorching along the cut surface.
Listen carefully to the sound of the motor. If you are feeding properly there will always be some slowing down, particularly with big cutters, but the sound must not become laboured. If it is slowing unduly, reduce the feed rate and/or the depth of cut in combination until the motor resumes a relatively free running sound.
Most beginners tend to be overcautious and feed the tool far too slowly in the mistaken belief that the finish will be better. In fact, bits will stay cooler, keep sharp for longer and produce a better cut surface if you increase the feed rate moderately.
The feed rate also needs to be one continuous operation at constant speed. Even the slightest hesitation in the speed of feeding will leave a scorch mark that is very difficult to remove with abrasives.
This is why it is always better to take a final very shallow cut to clean up any burning or roughness as you can make this pass really quickly without slowing the cutter.
When you reach the end of the cut, always lift the router by releasing the plunge lock while the power is still on and then switch off when the bit is clear of the work. If you try and switch off while the cutter is still in the cut, it will burn, but more importantly, the slightest wobble will cause an even deeper mark and the slowing cutter may try to grab the work, kicking the cutter sideways.
Similarly, you should always start the router with the cutter clear of the work and not in place in an existing cut. The starting torque will inevitably twist the router and cause the cutter to snatch.
Cutter Feed Direction
Of all the queries that the Trend technical support receives during the course of the year, the most common relates to confusion over the correct feed direction when using both hand-held or table-mounted routers.
One of the most important rules of routing is feed direction. This refers to the direction in which the workpiece is fed across the face of the cutter, or the cutter across the workpiece in relation to the rotation of the cutter. The golden rule is that for all routing operations the feed direction should oppose the rotational direction of the cutter.
What is important to remember is that when the router is above the cutter, shank pointing upwards, the cutter is rotating clockwise when viewed from above (see A). When the motor is beneath the cutter with the cutter shank pointing downwards, the rotational direction of the cutter is anti-clockwise when viewed from above.
Hand-held routing
When using the router as a handheld machine for edge rebating, planing or moulding, the rotational direction of the cutter is used to pull the cutter into the timber. This ensures that the fence is also pulled into the edge of the material. If fed in the opposite direction, the fence will tend to wander away from the edge leaving an irregular width moulding and making it more difficult to maintain a smooth and even feed speed. Also, there is the risk of the router running away from you creating a safety hazard.
Inverted routing
When routing on a table, that is with the router mounted beneath it, the feed direction is always from right to left (against the face of the fence). This ensures that the workpiece is pushed by the cutter against the table fence. If you attempt to feed from the opposite end, the workpiece will be pulled away from you. Not only will you not be able to machine the work successfully but you are likely to be set off balance, again setting up a safety hazard.
Overhead Routing
When using an overhead router, the feed direction should always be from left to right. Again the rotational direction of the cutter will pull the workpiece against the fence face. Feeding in the opposite direction will create an unsafe and unworkable situation as before.
Newcomers to routing often don’t realise that there is a right and a wrong way to feed the router. With certain exceptions the golden rule is that the feed direction should always be against the direction of rotation of the cutter. This ensures that the cutter is pulled into the work and whatever is guiding it is then pressed against the edge of the work. This way, the cutter will not wander off line and you will have no problem controlling it.
If you feed the wrong way, the fence or guide will try and veer off, the router may snatch and you will have great difficulty keeping it on line.
If you view your router from above, the cutter rotates clockwise and you need to feed against this, but the direction varies with the type of cut you are making.
For edge moulding the router has to be fed from left to right. Similarly, if you are using a straightedge or fence as a guide for internal cuts, the feed direction should always remain against the direction of rotation of the cutter
If you are moulding around the outside of a board, this means feeding the router anticlockwise when viewed from above.
If you are working round the inside of an opening, then the router has to be fed clockwise
Similarly, if you are using templates, external ones will require the router to be fed anti-clockwise.
But internal ones need feeding clockwise.
Cutting circles with a trammel is a similar situation, so the router must be fed anticlockwise to keep the cutter pulling out against the centre point of the trammel
It doesn’t matter if you push or pull the router as long as it travels in the right direction. Some cuts like rebates are often easier to make if you pull the router towards you but although the set-up may look different, it is actually the same as far as the router is concerned.
With solid timber, you also have to consider grain direction in conjunction with feed direction. As you make a cut across the grain it is likely that there will be some splintering or breakout as the cutter emerges from the edge.
If you are routing all the way around the board, make the end grain cuts first and then the break-out should hopefully be cut away when the side grain is cut.
If you are only making end grain cuts, eliminate breakout by clamping on a sacrificial support strip and machining right through into it.
Alternatively, plunge the cutter down to full depth on the exit corner of the board before you make the cross cut.
Progressive Cuts
When using large moulding or panelling cutters, the full depth of cut must be reached in a series of shallow steps.
Where the cutter features an open shape, each step can be made vertically, using the fine height adjuster to guide the cutter on each pass until the final depth is reached. The quality of the finish will be improved if the final cut is kept very light.
Where the cutter features a closed shape, increasing depths vertically is not possible. If a side fence or back fence (i.e. table fence) is used, then this can be adjusted using the fence to make incremental cuts.
For both straight or curved work, ball-bearing guided cutters can have alternative diameter ball-bearings interchanged before each pass, effectively increasing the width of each pass. This is imperative if small intricate workpieces are to be moulded safely.
In the cutter shown, the classic ball-bearing guided corner bead (Trend reference 9/55x1/2TC) is fitted with a 30mm diameter bearing (ref. B300A), then a 19mm bearing (ref. B19A) followed by the standard 12.7mm bearing (ref. B127A).
Backcutting
As with any rule, there are some exceptions and working with the cutter rotating against the direction of cut may not always be the best way if the grain orientation is difficult. Rebates in solid timber often show minor damage to the wood fibres along the bottom edge of the cut.
For a really clean cut across end grain, or where the grain is very swirly, it is permissible to use the backcutting technique as long as you exercise caution and remain vigilant to the potential problems of ‘cutting the wrong way’!
Backcutting when using a dovetail jig involves making a very shallow initial cut, but feeding the router with the direction of rotation of the cutter.
Once the fibres have all been scribed neatly, you can make the rest of the cut to full depth, feeding the router in the conventional way.
If you are edge moulding, some timbers may have diagonally orientated grain and there is then the possibility of it splitting out ahead of the cutter. This can be overcome by backcutting first before making the main cut.
Circular work is another potential routing problem area as there are so many different grain surfaces exposed. You are bound to end up cutting against it somewhere. In this situation, you can make several successive, but very shallow passes cutting the ‘wrong’ way in the difficult areas.
A straight forward edge mould can sometimes look ok, but in reality it feels as if the surface is covered with a series of tiny ripples. This can usually be cleaned up by firmly pulling the router backwards at the same setting as you have just used to make the initial cut. Theoretically, it shouldn’t remove any more timber, but the smoothing effect is often amazing.
Your first cut
Quick guide
You should now be thoroughly familiar with your new router and all its components, so it is time to put it all into practice and start building some confidence in its use.
If you are a real first time user, try this simple exercise, cutting a 3/8” deep by 1/2” wide groove using the standard side-fence for guidance. A medium sized router should be able to make this cut in one pass, but if you have any doubts do it in two stages.
1. First check the router is unplugged from the power supply.
2. Fit a straight 1/2” diameter cutter into the collet making sure at least 3/4 of the shank length is engaged within the jaws.
3. To set the depth of cut, release the locking lever or knob and plunge down until the cutter tip rests on the surface of the bench and lock it in that position.
4. Now set the depth of cut by adjusting the depth rod until there is a 3/8” space between it and the turret stop. Use either a rule or spacer blocks.
5. Release the plunge lock and allow the router to spring back to the resting position
6. Fit the side-fence to suit the position of the intended groove and lock it up tight on the rods, making sure these are also held firmly in the router base
7. Clamp the workpiece firmly to the bench making sure the cramp will not impede the path of the router.
8. Check that the router switch is off and then plug in
9. Switch on the router and let it reach full speed.
10. Position the cutter over the work and plunge down to the preset depth and lock.
11. Quickly start moving the router forward until it reaches the end of the cut,maintaining pressure on the side-fence to keep it against the edge of the timber
12. Release the plunge lock, turn off the router and allow the cutter to come to rest before putting it down
